AMIG 211
AMIG 211
| General information | ||||||
| Model | AMIG 211 | |||||
| Total Weight | 9000 Kg | |||||
| Capacity of Bucket | 0.3-0.4 m³ | |||||
| Dimension L*W*H | 6500*2370*2750 mm | |||||
| Engine | ||||||
| Model | YAMAR or YUCHAI | |||||
| Rated Power | 60 Kw/2200 rpm | |||||
| Max. Torque | 275 N.m | |||||
| Hydraulic System | ||||||
| Pump Model | SKS (Saikesi)(JAPAN) | |||||
| type of Pump | Variable double- Piston Pump | |||||
| Max. discharge flow | 90 ml | |||||
| Hydraulic pressure | 28 Mpa | |||||
| Travel System | ||||||
| Travel Motor | JEIL (KOREA) | |||||
| Swing Pump | JEIL (KOREA) | |||||
| Swing Speed | 12 rpm | |||||
| Working Range | ||||||
| Max.Digging Height | 6500mm | |||||
| Max. Digging Depth | 4300 mm | |||||
| Max. Dumping Height | 4500 mm | |||||
| Boom Length | 3820 mm | |||||
| Bucket Arm Length | 2330 mm | |||||
| Shoe Width | 450 mm | |||||
| Capacity | ||||||
| Fuel Oil Capacity | 240 L | |||||
| Capacity of hydraulic oil tank | 130 L | |||||
